Description
automatic bag-feeding packaging machineApplication:
Suitable for automatic measuring and packaging of large and irregular particles such as chicken bouillon, candy, nuts, raisins, peanuts, sunflower seeds, kernels, potato chips, chocolate, biscuits, etc.
Suitable bag types: stand-up pouches, zipper bags, four-side-seal bags, three-side-seal bags, paper bags, and other composite bags.
automatic bag-feeding packaging machine Technical Specification：
| Model | KY-D250 |
| Packing speed | 10-45 bags/min |
| Packing bag size | Bag Width：100-250mm
Bag Lenth: 100-380mm |
| Packing weight | 100 – 2500g |
| Air consumption | ≤0.7m³/min |
| Voltage | 380V |
| Total power | 2.3 kw |
| Dimensions | L4070 * W2820 * H3700mm |
| Gross Weight | 1600kg+200kg+300kg |
| Precision | ≤ ±1% |
automatic bag-feeding packaging machine Configuration Details:
-
Main Unit: KY-8R250 (includes ribbon printing/coding)
-
Z-Type Elevator & Platform
-
10-Head 2.5L Hopper Electronic Scale
automatic bag-feeding packaging machine Workstation Accessories:
-
Ribbon printer/coder
-
Top & bottom bag opening device
-
Hopper vibration device
-
Bottom vibration device
-
Exhaust/deaeration device
automatic bag-feeding packaging machine Machine Dimensions (approx.):
-
Length: 4.5 meters
-
Width: 2.8 meters
-
Height: 4 meters
(Refer to the detailed diagram below for specifics.)
Packaging Machine Operation Process:
-
Manual Bag Placement: Operator places bags into the bag holder.
-
Station 1 – Bag Feeding: First station picks up the bag automatically.
-
Station 2 – Coding & Zipper Opening:
-
Ribbon printing/coding (optional: inkjet/laser coding available at additional cost).
-
Servo-controlled zipper opening mechanism.
-
-
Station 3 – Bag Opening:
-
Top & bottom bag opening device.
-
Sensor detects if the bag is properly opened and signals the electronic scale to discharge material.
-
-
Station 4 – Filling:
-
Material is filled into the bag.
-
Bottom vibration ensures even settling of the product.
-
-
Station 5 – Fill Check:
-
Sensor verifies if filling is complete and signals whether to proceed with sealing.
-
-
Station 6 – Gas Exhaust:
-
Sponge compression reduces air inside the bag.
-
-
Station 7 – First Sealing: Initial sealing for bag closure.
-
Station 8 – Second Sealing: Reinforced sealing for added durability.
Packaging Machine Requirements:
4.1 Power Supply:
-
The buyer’s factory must provide a three-phase 380V power supply.
-
The main power cable connected to the host machine must be a 4mm² three-phase four-wire cable.
4.2 Grounding:
-
The equipment requires a proper grounding connection for safety.
4.3 Air Supply (Compressed Air System):
-
Air compressor: 7.5KW (recommended: variable-frequency direct-drive screw type).
-
Air storage tank: 1 cubic meter.
-
Air dryer: 1 unit (capable of supporting 3 machines running simultaneously under normal conditions).
4.4 Air Pressure & Connection:
-
Working pressure: 0.7 MPa (7 bar).
-
Air hose diameter for host machine connection: 12 mm.
Machine Configuration touch screen SMART 700IE V3 Siemens PLC SIMATIC S7-200 CPU ST30
EM DT08
Siemens Frequency converter 1R5G-T3 Anbang letter Main motor JCSA67-20.37-Y1.5-4p Morning tide Solenoid valve 5V210-08 DC24V 1.6W
AirTAC encoder E6B2-CWZ6C-360 OMRON Cylinder TCM16*50S AirTAC Upper bag cylinder DSNU-16-20-P-A Germany Festo Power Supply ABL2REM24020K Schneider Intermediate relay Exm2lb2bd24voc Schneider Solid state relay KSR-10DA 24-380VAC Yangming
air switch 1PC16A 1PC10A
Schneider Vacuum pump WZB25-P-T Yunwang vacuum solenoid 3v310-10-nc DC24V.30w
AirTAC Contactor LC1N12 10D3N Schneider Splitter 06-120-2L-S3 Faulkson Sliding membrane JUM02-25 JUM02-30
Igus Oil and water filter GFR300-08 AirTAC
Vacuum filte GFR200-08 AirTAC
